Antrea Kubernetes Networking Software Review
antrea.io · checked 15 Oct 2026
Open-source Kubernetes networking and policy software for pods, nodes, virtual machines, and bare metal.
How it plugs in
Signal on Microsegmentation Software7.4#1 of 31
Antrea is a Kubernetes Container Network Interface (CNI) that supplies pod networking and security rules. It uses Open vSwitch, supports overlay or non-overlay networks, and runs on Linux and Windows nodes. Antrea adds policy tiers, cluster and node rules, diagnostics, Prometheus metrics, and multi-cluster features. It is self-hosted and free under Apache 2.0.

Review
In a line
Antrea is open-source networking and security software for Kubernetes. It provides pod networking and enforces Kubernetes NetworkPolicy rules.
What it does
Antrea uses Open vSwitch as its networking data plane, including Kubernetes Service load balancing. Networks can use VXLAN or Geneve overlays, or run without an overlay when the infrastructure allows it.
Its policy system adds tiers, rule priorities, cluster-wide policies, node policies, and application-aware Layer 7 HTTP and TLS rules. Policies can also cover virtual machines and bare-metal nodes outside Kubernetes.
Clusters can be federated with shared networking, multi-cluster Services, and a common security posture. IPsec or WireGuard can encrypt pod traffic between Linux nodes; Windows nodes do not support this traffic encryption.
How it connects
Antrea runs inside user-managed Kubernetes clusters on private cloud, public cloud, or bare metal. It supports Linux and Windows nodes and has API, self-hosted, and hybrid deployment options.
The project provides a public API reference and the antctl command-line tool for diagnostics. It exports metrics to Prometheus and documents integrations with Prometheus, Octant, Multus, Fluentd, and Theia, which adds Grafana-based flow views and policy recommendations.
Installation can use one YAML manifest, Helm, or cloud-specific instructions. Guides cover Amazon EKS, Azure AKS, and Google GKE; GKE is marked Alpha.
Good fit
Antrea suits teams managing Kubernetes networking and policy themselves. It is useful when you need segmented traffic, centralized control, multi-cluster networking, or policy visibility.
Diagnostics include packet tracing, policy analysis, and flow inspection. The project also documents APIs, encryption, Windows operation, integrations, and developer workflows.
Watch for
Clusters need NodeIPAMController enabled and the Open vSwitch kernel module on every Kubernetes node. The project says it has been tested with Kubernetes 1.23 and later.
Azure AKS support is no longer tested from Antrea 2.5 onward, so Azure issues are handled on a best-effort basis. Encryption between nodes is unavailable on Windows.
Antrea 2.7.0 warns that rolling updates on large clusters can briefly disrupt Egress and ServiceExternalIP ownership. Its security policy asks for private reports and does not currently assign CVE identifiers itself.
Pricing
Antrea is free open-source software under the Apache License 2.0. There is a free plan and no free trial because the project has no paid plan described here.
Verdict
Choose Antrea if you operate Kubernetes clusters and want an open-source CNI with expanded policy controls, diagnostics, and multi-cluster features. It is also a candidate for mixed Linux and Windows environments, provided you can accept the Windows encryption gap.
Look elsewhere if you need vendor-tested Azure support, encryption on Windows nodes, or a managed service instead of running the networking stack inside your own clusters.
Our take
Antrea makes sense for organizations that already run Kubernetes and can manage cluster networking components. Its free Apache-licensed model removes purchase cost, while policy tiers, cluster and node rules, diagnostics, and federation cover demanding network-control tasks. Check the Open vSwitch and NodeIPAMController prerequisites first. Windows users should account for the lack of encrypted pod traffic, and Azure teams should treat support as best effort. Large-cluster operators should review the documented rolling-update disruption warning before adopting version 2.7.0.
- Free and open source under Apache License 2.0
- Adds tiers, priorities, cluster-wide, and node network policies
- Supports VXLAN, Geneve, or non-overlay networking
- Includes diagnostics and Prometheus metrics export
- Works with Linux and Windows Kubernetes nodes
- Requires Open vSwitch kernel support on every Kubernetes node
- Windows nodes cannot encrypt pod traffic with Antrea
- Azure support is best effort from version 2.5 onward
- Large-cluster rolling updates may briefly disrupt some ownership
- The project does not currently assign CVE identifiers
- Pick it ifTeams running self-managed Kubernetes clusters; Kubernetes network segmentation and multi-cluster operations; Mixed Linux and Windows node environments
- Skip it ifYou need encrypted pod traffic on Windows nodes; You require tested, fully supported Azure deployment; You want a managed networking service instead of self-hosting
Pricing
The Antrea plan costs free and uses the Apache License 2.0. It requires your own Kubernetes cluster and the Open vSwitch kernel module on every node; there is no paid tier or trial.
- AntreaApache License 2.0 · requires a Kubernetes cluster and Open vSwitch kernel module on every Kubernetes nodeFree
As antrea.io lists them, checked 3 Oct 2026.
Questions
Is Antrea free?
Yes. Antrea is free, open source, and released under the Apache License 2.0. There is no paid plan or free-trial period listed.
Which Kubernetes versions does Antrea support?
The project says it has been tested with Kubernetes 1.23 and later. Each node also needs the Open vSwitch kernel module, and NodeIPAMController must be enabled.
Does Antrea run on Windows?
Yes. Antrea supports Kubernetes nodes running Windows, but IPsec or WireGuard encryption for pod traffic between nodes is not supported on Windows.
What cloud platforms have deployment guides?
Documentation covers Amazon EKS, Azure AKS, and Google GKE. GKE is marked Alpha, and Azure support is best effort from Antrea 2.5 onward.
How do I install Antrea?
A standard installation applies one YAML manifest. Helm and cloud-specific deployment guides are also documented.
Does Antrea have an API?
Yes. The documentation lists Antrea API groups and a generated API reference. The antctl command-line tool supports diagnostics and operational inspection.
