L

Projection Mapping Software

LightAct

lightact.com · checked 30 Sept 2026

How it plugs in

—Public API
NoOpen source
YesFree tier

Signal on Projection Mapping Software6.0#11 of 24

LightAct is software and hardware for live events and immersive fixed installations, including projection mapping.

LightAct home page

Review

LightAct combines software and hardware for live events and immersive fixed installations, including projection mapping. Its Layer Layouts coordinate video and audio playback with conditional logic and messaging to third-party apps. The projection workflow uses 3D mapping, camera-projector calibration, and manual warping and blending. Multi-server clusters can distribute workloads and synchronize frame by frame. Integration options include Notch blocks, TouchDesigner components, and Unreal Engine. Content I/O includes Deltacast, Blackmagic, DirectShow-compatible sources, NDI, Spout, and Unreal Texture Share. LightAct supports OSC, TCP, UDP, and TUIO messaging, as well as third-party camera and object tracking with a Tracking Visualizer. Its customizable browser-based WebUI is available only on LightAct servers. The software is self-hosted on Windows; documented minimum requirements are Windows 10 or later, a discrete Nvidia graphics card, and at least 8 GB of RAM. It does not support receiving or sending interlaced video streams. The free Creator plan unlocks all features and unlimited outputs, but watermarks the outputs. Easy Perpetual costs 1,770.00 EUR once.

Our take

LightAct covers projection and live-event workflows with multiple integration and control options. Check the Windows requirements, output watermarking, and interlaced-video limitation before choosing a plan.

  • ["3D projection mapping with calibration and blending tools", "Multi-server clusters synchronize frame by frame", "Supports Unreal Engine, Notch, and TouchDesigner", "Includes tracking visualization", "Free Creator plan unlocks all features"]
  • ["Creator plan watermarks outputs", "Requires Windows 10 or later and Nvidia graphics", "Does not support interlaced video streams", "WebUI is available only on LightAct servers"]
  • Pick it ifLightAct suits teams producing live events or immersive installations that need projection mapping, synchronized multi-server work, or tracking. It is aimed at Windows deployments with the specified graphics and memory requirements.

Pricing

  • CreatorAll features unlocked · unlimited outputs · outputs watermarkedFree
  • Easy Perpetual UpgradeEasy license tier upgrade€295 one-time
  • Easy PerpetualUp to 2 x 4K outputs · standalone server · streamlined feature set€1,770 one-time
  • Live PerpetualPlease contact us for pricing. · Up to 8 x 4K outputs · advanced features including object and camera trackingOn request

As lightact.com lists them, checked 30 Sept 2026.
